Hydraulic Extendable Trailer

The hydraulic extendable trailer is available in 3x4 or 4x4 tyre configurations and can be customised to suit your transport requirements.
Availability:
Product Description

The hydraulic extendable trailer is available in 3x4 or 4x4 tyre configurations with hydraulic trailer suspension and can be customised to suit your transport requirements.

For reliable product support and spare parts, you’ll love the extendable trailer by us

Available in 3x4 or 4x4 tyre configurations.

Customised to suit your transport requirements.

Designed and manufactured with the highest quality materials and workmanship to suit the most demanding tasks of extendable pipe trailer.

Reliable product support and spare parts.


hydraulic-extendable-trailer-carry-with-wind-turbine-blade

hydraulic extendable trailer

hydraulic-trailer-with hydraulic-suspension-and-hydraulic-steering

hydraulic trailer


Features

●Stainless steel hydraulic tubing

●Multiple section extendable chassis to 45m

●10R 20 tyres with heavy duty underslung air bag suspension

●hydraulic link steering with radio controlled

●Rear push point

●24V 3Kw electro – hydraulic power pack

●2 x spare tyre carrier brackets

●Grit blasted and painted in 2 pack paint

●Heavy duty landing legs

●LED lighting

●Dunnage trays and lockable tool boxes


Product Number

I)Overall Dimensions
a.Overall Length 62000 mm
b.Over all Width 2700 mm
c.Overall Height 1640±100 mm
d.Fifth wheel height 1350mm
e.Drawing No. 62m2018


II)Under Chassis Assembly - Axle
a.Type   M/S YUEK -  Axle
b.Number of Axle  3 Axles
c.Distance between Axle centre 1800mm
d.Kingpin 2.5 inch


III)Tyres
a.Make To be specified
b.Size  10.00 x R20 Radial
c.Number of tyres 12+1 Spare
IV)Wheel Rim
a.Make To be specified
b.Size 7.50” x 20”


V)Boom
a.Material Q550D
b.Type 3 stage middle extension
c.Boom lock frequency 1no. per m
d.Boom lock mechanism Pneumatic
e.Lock booster size 24/27


VI)Suspension
a.Type Air suspension
b.Air bellow dia 320mm
c.Air bellow stroke 200mm
d.No. of air bellow 2nos / axle
d.No. of air bellow Komman


VII)Steering
a.Auto Mode No
b.Energy Chain No
c.Steering Mechanism Turntable
d.Steering Angle 50 degrees
e.Control Wireless remote control + Wired option control + Emergency lever control
f.Pump pressure Minimum 6 Litres / minute


VIII)Accessories
a.Landing gear 1nos 25MT Jost fixed + 1no Hydraulic
b.Size 7.50” x 20”
b.Size No


IX)Aesthetics
a.Paint Color RAL 3002
b.Paint Thickness 1 coat rust proof primer + 2 coats paint. Minimum thickness to be 80micron


FAQ

Q:Did this trailer suitable for wind blade?

A:Yes,this trailer majority for wind energy.

Q:Did this trailer exported?

A:Yes,export to more than 20 country.
