Depending on the purpose these versatile vehicles are equipped with with self-steering axles, hydr. steered axles or swing axle systems. We offer Extendable Low Loader Trailer and not-extendable low bed trailer.
Extendable-low-loader-trailer-8-axles
Airbag-suspension-low-bed-trailers
Extendable-trailer-carry-VESTAS-wind-tower
extendable trailer
Ramp-low-bed-trailer-80-ton
60ton-Lowbed-trailers-ready-for-delivery
They are suitable for heavy, bulky goods, for example fork-lift trucks, working platforms or construction vehicles.
5-axles-extendable-low-loader-trailer
6-axle-Low-Loader-extendables-for-Kazakhstan
Features
All extendable trailer can be ordered equipped individually with a variety of components in various combinations
Depending on the design the following options are available e.g.:
Container Locks
loading platform with hardwood
steered axles (self steering/ hydr. steered)
lifting axles
air suspension
pendular / pendle axles
widenings
Purchased components such as hydraulic, lighting, electrics, brake systems and axles come from the ranges of renowned suppliers.
Extendable-low-loader-trailer
China-heavy-duty-low-bed-trailers
32-wheels-low-bed-trailer-100-ton
80-ton-lowbed-trailer-for-Africa
Product Number
Framework trailer | 8 axis | |
The effective length of the dock(mm) | 19169+10000 | |
Width of the dock(mm) | 3200 | |
Height of the dock(mm) | 1100 | |
Total Height(mm) | 1950 | |
Wheelbase(mm) | 7739+1310*7 | |
Deadweight(kg) | 27000 | |
Each axle of maximum load(kg) | 13000 | |
Gooseneck for truck | 6*2,6*4,8*4 | |
Tire | 235/75/R17.5 18pr（Triangle） | |
Rim | 17.5*6.75 | |
Amounts of tire | Total 32+4 | |
kingpin | 3.5”,2” | |
Total NO. of | 8 | |
No. of turning axle | 6 | |
Suspension Mode | Leaf spring suspension | |
Power unit | ||
Diesel Models | KM290F | |
Power | 24.1KW/L | |
Pump | Europe and Asia II | |
FAQ
Q:How many axle can be use on lowbed trailers ?
A:2-12 axle is available on low bed trailers
Q:what is Max pay load for lowbed trailer?
A:Up to 140 ton loading capacity of Rui's lowbed
